8p8c panel mount ethernet modular jack waterproof rj45 connector

8p8c panel mount ethernet modular jack waterproof rj45 connector

Place of Origin:
Guangdong, China (Mainland)
Brand Name:
CNLINKO,OEM
Model Number:
LP-24 RJ45
Type:
RJ45, IP67 signal connector
Application:
Signal
Gender:
Male
Number of contacts:
8 pin
Wire Size:
0.15mm2 ~ 0.2mm2/26~24 AWG
Rated Current:
1.5A
Housing&Insulation material:
High-performance engineering plastics
Metals material:
Zinc alloy(pearl hard chrome)
Certificate:
CE,RoHS,UL
Product Keywords:
waterproof rj45 connector
Packaging Details
Export carton, Size 17cm(L) x 8cm (W)x 6 cm (H), 10pcs/Carton, 0.0008M3 per carton, Net weight: 0.5KG, Gross weight: 0.54KG
Delivery Time
3-7 days
About LP 24



LP-24 series contains RJ45,USB,Power and fiber optic.Design snap lock ensures stable and security firm, Using nickel plating alloy , Shell made of materia PBT, Gold-plated, high strength corrosion resistance, and electrical conductivity. Socket and internally made of zinc alloy, with well protected electromagnetic and radio frequency interference.

Product Description

8p8c panel mount ethernet modular jack waterproof rj45 connector

Product details

Type IP67 signal connector
Number of contacts 8 pin
Wire Size 0.15mm2 ~ 0.2mm2/26~24 AWG
Rated Current 1.5A
Housing&Insulation material High-performance engineering plastics
Metals material Zinc alloy(pearl hard chrome)
Certificate CE,RoHS,UL
Product Keywords waterproof rj45 connector

LP-24 SERIES SPECIFICATIONS SHEET

TYPE 3PIN POWER RJ45 USB OPTIC FIBER
Cable specification 2.5mm2~4mm2/
14-12AWG
0.15mm2~0.2mm2/
26-24 AWG
Diameter range Φ8mm~Φ12mm Φ5.5mm~Φ7mm
Contact diameter × number 3.0 x 3 8PIN 9PIN(3.0)&4PIN(2.0) 2
Rated Current (A) 20A 1.5A /
Operating voltage (AC.V.rms) 500V /
Contact resistance <1mΩ <30mΩ /
Temperature rise 20A contact temperature below 30℃
25A……40℃↓,
30A……50℃↓.
/
Withstanding Voltage (AC.V)
1 minute
2500V 1000V
Insulation resistance >500MΩ
Protection level IP65/IP67
Durability ≥500 times
Working temperature  -40℃~80℃
Connecting mode Easy locking type
Assembly wire Soldering/Crimping /
MATERIALS
Housing&insulation parts high-perpormance engineering plastics
Hardware zinc alloy(pearl hard chrome)
copper pins copper alloy
(gold-plated 4U)
waterproof cover Silica gel
Flammability rating UL94-V0

All Series

Why Choose Us

        Quality

  • Our quality control team will inspect every process from material purchase, injection, metal stamping, production assembly, finished products.
  • We strictly produce products according to ISO9001
  • 100% tested before delivery(Not Just Batch Tested),almost zero complaint.
  • Reliable quality product,competitive price than other famous brands.
  • International level laboratory ,flexible production line, lean production.
  • We only use good materials from suppliers such as SABIC, DU PONT.



     Production

  • Monthly output for every series product is 500000 sets
  • State-of-the-art production facilities and standardized work flows guarantee quality
  • For our standard product, we provide very fast delivery time from 3 days to 7 days

     Company policy

  • Continuous innovative design make us leading the industry
  • Our vision is to achieve high customer satisfaction through continuous improvements in quality, delivery and service.
  • Our target is to create a good working environment which employee could work happily , treat the company as their own home.

      Team

  • Experienced and passion team ,with international vision and serious business attitude.



      Professionalism

  • Factory more than 12 years history, dedicate in industrial connectors R&D and manufacturing only
Company information

Production Process

Laboratory and Test
Application
Professional Certificate

Exhibition

FAQ

Q1. Can I have a sample ?

Yes, we welcome sample order to test and check quality. Some samples are free, and some samples should be paid in advance and the cost will be refund after further order.



Q2. What about the production lead time?

It will take about 3 days to 7 days for our standard product .



Q3. Do you have any MOQ (minimum order quantity) limit?

Low MOQ, 1pc for sample checking is available.



Q4. How do you ship the goods and how long does it take to arrive?

We often ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.



Q5. Is it OEM available?

Yes. We have rich experience and good ability to put your design and idea into real product, normally it take about 20 to 30 days for new product from mold design to final production.



Service

1. We will reply your inquiries within 1 hour to 24 hours.

2. We provide 1 year quality warranty period.

3. We always try our best to keep our words.

4. We provide customized solution according to your requirement.

5. Our goal is to create maximum value for our customers and partners around the world.
